Description
 |
SRI No. |
OEM No. |
Width |
PL-1
SE
(A) |
PL-1
LE
(B) |
Arch
(C) |
No of Leaves |
Pack Thck
D |
Spring Capty. |
Remarks |
43-1261 |
F81Z5560BA 81A5560BE |
3 |
25 |
33 1/4 |
7 7/8 |
4/1 |
2 1/4 |
3,000 |
Single Rear Wheels; Two stage |
These leaf springs are made to meet or exceed OEM specifications and standards. These springs are made to replace the OEM leaf springs. Replacing broken or worn leaf springs keeps your truck safe for you and everyone you share the road with. Please call us toll free (1-877-774-6473) if you need assistance identifying your spring.
NOTE: Replacement of hardware does not over compensate the factory overload. Please call us for assistant at 1-877-774-6473.
Features
- OEM Quality
- Made to fit
- Painted to protect from rust
Notes
- U-Bolts WILL NOT work with factory contact overloads
- Spring Code Will Help Ensure Proper Spring Replacement. The Spring code is located on a sticker on the inside Driver Side Door jam, Bottom Right hang corner under "SPR" or "Spring" will be a 2-4 Character Code.
-
Specifications and diagrams are listed on the previous page. If you need further assistance, please contact us
- Professional installation and tools may be required
-
Average Shipping Time: 4-7 Business Days
Vehicle Applications
-
Years: 1999, 2000, 2001, 2002, 2003, 2004
-
Model: Ford F250SD, F350SD Pickup 2wd 4wd Single Wheel
OEM Replacement Leaf Spring 43-1261 FAQ with SD Truck Springs
Q: I want to replace my leaf springs but I dont know what leaf springs I have. Can you help me out?
A: Sure thing, In order to identify what leaf springs your vehicle uses you need to locate your spring code or SPR code. On Ford vehicles this number can be found on a sticker located on the driver door panel. The 43-1261 Rear Leaf Spring works on Ford F250/350s anywhere from 1999-2004.
Q: Does this come with the front leaf spring too?
A: Because of compatibility issues, Leaf Springs are sold individually due to the fact that springs are offered for both the front and the rear of many vehicles. This specific item offers one rear leaf spring for the 1999-2004 Ford F250,350 4wd with 4 leaves in the pack.
Q: How much weight can these springs handle?
A: The spring capacity for the 43-1261 front leaf spring is 3,000 lbs. This leaf spring also offers additional hanger/shackle kits and eye bolts if you need to replace the ones you have in the future
Customer Reviews
4.5 / 5This item is rated 4.5 out of 5 based on 37 customer reviews.
by
Timothy B
The quality was good but the height of the front and back were different. I ended up adding 2inches of lift to the back to level out the Excursion. I have extra weight in the front and less then normal in the back but still was not enough to level it. I like the overall height now but wish I didn't have to add a block to make it level. Possibly adding a spring would have helped but that was out of my knowledge.
by
Matthew l
The leaf springs squeaked real bad over every small bump the day after I installed them. So I was able to quiet it for the most part by putting some chain lube where the plastic circles are in between the leafs. Hopefully the noise doesn't return
by
Eldon B
Very satisfied. Had my mechanic do installation. No problems with install. Absolute correct parts. Cannot tell any difference in ride or performance from original equipment. Thanks for your help. Customer service was excellent.
by
Ray S
I ordered front and rear leaf springs with all the hardware. Installation went well. The springs are top quality and improved my ride tremendously. Highly recommend.
by
Sauron S
Parts fit as suggested. I have towed with them and seem to be operating as intended.
by
Robert T
Best price out there! Exactly what we ordered, custom made bolts fit perfectly. Would definitely recommend this product and company to a friend. Thank you!
by
Brian D
Springs went in good, no issues. They arrived UPS and I assisted the driver in getting them off the truck, they're HEAVY. Had an issue with receiving the wrong U-Bolts, contacted support and they shipped the correct bolts quickly. Overall, good experience with SD Truck Springs.
by
Nicholas D
Great option to replace my sagging and cracked stock spring set. 300k miles had taken its toll on my stock springs. Picked up about 1" of lift and much better load handling.
by
Alex B
The springs are working out great but my concern is the hardware, specifically the u-bolts. They are showing a lot of rust. There was no clear instruction on if the u-bolts had to be coated in something. Please get back to me if I am still ok or not with the u-bolts I bought from you. Thank you.
by
Gavin B
Springs were strong. They rust way too fast though. i installed very easily and customer care are very supportive and diligent .I would suggest covering them in something else besides just paint
by
Peter D
Excellent Product. Old leaf springs were shot. Truck now sits 3 inches higher and rides like new. Well worth the money. Customer support was great. Thank you.
by
Andrew D
Fit was fine I had 4+ contact overload springs on my 2003 F250 and in order to install the contact overload springs the pack had to be unbolted so spacer then contact spring could be installed. I don’t know if SD had an option for one already installed but that would have made the install much nicer and easier. One spring was missing the anti squeak pad on the ends but I have not noticed an issue as of now.
If done again I would probably upgrade the rear to the 6+1 but I would recommend SD spring.
by
Frank D
Springs were exact fit and easy to install. Pricing was fair. No special tools needed to install. The springs perform as expected.
by
Jason M
Leaf springs are great! Easy to install and affordable. I will definitely order more parts from SD truck springs.This leaf spring also offers me additional hanger shackle kits and eye bolts if somewhere I need to replace the ones you have in the future . Thank you SD team you guys done a gr8 job
by
kai h
Great improvement in ride height and ride quality over my stock Excursion springs.
by
theresa k
They worked fine! Very happy! They were easy to install. i recommend every one for this kit. cuStomer care very diligent . gr 8 keep it up SD truck
by
jim l
Would you recommend this product to a friend? Yes
Did the product perform as expected? Yes
Did you get the support you expected? Yes
Did you use any special tools to install? No
Were the springs easy to install? Very easy
Did you compare prices with dealer or others? Yes
Did you like the SD Truck Springs process. Yes
by
David P
Arrived well palletized. The third party came up short on bolts, but SDTruckSprings made it right with upgraded shipping. I have to assume the springs are rated as described. Quality finish on springs.
by
Reinier d
The price was good and shipping went well. Install didn't go as well. The springs are held together by a bolt and nut in the middle. The bolt and nut are bigger than what is on the OEM springs so it won't fit. If you have a helper spring, there is a metal spacer that sits on top of the spring. The spacer has an indentation in the middle that falls over the bolt and nut from the spring. When I asked SDtrucksprings for help it took a while to get a response. The response was useless, they suggested to buy a different spacer (didn't even offer to pay for it). The offered spacer simply has a hole int he middle and it will fit but it won't have a pin sticking up to center the helper spring. Disappointed about the lack of a good solution for this. In the end I ended up cutting off the bolt that sticks out on top. SDtrucksprings did not offer this solution.
by
Charles v
I used these springs on a 2005 Excursion 6.0, with the "B Mod". Vast improvement over stock handling. Less or almost no wallow and in a different category for towing a heavy travel trailer. Good springs. If the OEM Ford springs are any better, I will never know because these do the job for far less money. I have never installed leaf springs and putting them on was not very difficult for me to do.
by
Jared N
Very good replacement springs for my f250, I replaced my springs with these springs when mine broke. They ride well and also even gave my truck a little lift also, would definitely recommend these if your springs are worn out.
by
Timothy S
ordered these for my 2003 F250 SD, Best price anywhere, fast shipping(4 days to my door), all hardware included.
Exact item I needed to replace a broken spring, brought my truck back to normal ride height and weight capacity.
I would recommend these leaf springs and sdtrucksprings.com to everyone.
by
Jonathan M
Ordered these and they showed up quickly and fit perfectly. Highly recommend the springs and this company.
by
Darin F
These were a perfect match for my Excursion leaf spring swap. They were great quality and fit great. highly recommend.
by
Justin B
I bought the Xcode fronts first and install them. I like the way I would not bottom out anymore but I had a sagging rear end so I bought these springs to help level out the truck. on the excursion I still have a little bit of sag to the rear it I should have gotten the larger blocks but I use the original blocks if I had to do it over again I would use different blocks or order longer springs
by
dustin E
Fits like it should. Fast shipping and good customer service. Great value
by
Austin W
The leaf springs I order were exactly what I expected. The hardware kit was great. Should have remembered I needed u bolts long enough for the helper springs. Shipping was fast in my opinion. I would order from struck springs again.
by
Jeremy B
Leaf springs were great, matched original well. Bushings were too tight for factory size bolts and nobody had right size so we just ran a 3/4" drill bit through it. Springs do come painted, but are already rusty after few months. Other than that I'm happy, price couldn't be beat!
by
KENNETH S
I bought the Leaf Spring and I have't say, that it doing fine me and my family.
by
Scott B
Product is great, the support i received was even better. Thank you!!!
Displaying 1 to 30 (of 37 reviews)
